DAQUAN waterproof partition wall features: DAQUAN waterproof
partition wall has a good waterproof, moisture proof performance, can be used
in the wet area such as kitchen, toilet, basement, wall will not loose, active
magnesia, deformation or strength
degradation phenomenon by absorption of moisture.
DAQUAN waterproof partition wall using
scheme
/
Product one
DAQUAN lightweight sandwich wall
panel is a kind of light weight energy saving wall material taking calcium
silicate board as face board, with cement, EPS (polystyrene foam particles),
sand, fly ash as core material forming by one time compound.
Wall panel specifications:
Length: 2270, 2440
mm
Width: 610 mm
Thickness: 50, 60,75,90,120,150,180,200mm
Weight：45-95kg/m2
Applications:
1) widely used in all kinds of old and new building
non-load-bearing internal and external
walls;
2) for kitchen, toilet, basement waterproof
demand higher occasion;
3) suitable for steel structure internal and external
wall;
4) suitable for old
building reconstructing partition wall, the floor has requirements
for bearing.
Product two:
Lightweight solid panel, taking cement, EPS (polystyrene
foam particles), sand, fly ash as core material forming by one time compound.
Wall panel specifications:
Length: 1800 mm
Width: 610 mm
Thickness: 90,120,150,180,200mm
Weight：40-60kg/m2
Applications:
1) widely used in all kinds of old and new building
non-load-bearing internal and external
walls;
2) for kitchen, toilet, basement waterproof
demand higher occasion;
3) suitable for steel structure internal and external
wall;
4) suitable for old
building reconstructing partition wall, the floor has requirements
for bearing.
1、Waterproof
Experiments show that DAQUAN
waterproof wall without plaster can be made into containers take water, without
any leakage. It has a good waterproof, moisture proof performance, can be used
in the wet area such as kitchen, toilet, basement, wall will not loose, active
magnesia, deformation and strength degradation phenomenon by absorption of
moisture. Wall also won't appear the condensed water bead in wet weather, and
generally masonry cannot be moisture proof,will appear batch swings layer
stripping phenomenon after time is long.
2、Lightweight, Space cost saving
DAQUAN waterproof wall panel is a
kind of solid core thin body new wall materials, materials of lightweight, greatly reduce the bearing
of the construction. Its thickness between 90 mm - 200 mm, compared
with traditional block thickness greatly save the building space. For example:
traditional block add plaster with an average thickness of 240 mm + 40 mm, and DAQUAN
lightweight panel thickness of 90 mm do
interior partition can meet all the requirements
and achieve national testing standards.
3、Easy construction, Shorter time
DAQUAN waterproof wall panel
construction is precast construction, the whole assembly or construction process is simple,
effective, no construction waste, no plaster, shorten the construction time.
Traditional block wall need 12 people 60 minutes construction, use DAQUAN lightweight
partition panel only need 3 people 60 minutes to complete, save a lot of labor
cost.
4、 High strength, Earthquake proof,
High safety
DAQUAN waterproof wall panel take
prefabricated construction, the overall intensity is high, the seismic performance higher than that of
the masonry wall dozens of times, anti-impact performance higher than that of
the masonry several times, under the impact force of 50 kgs, without a
slightest transfixion crack, overall no deformation, surface without loose
marks; DAQUAN lightweight wall panel can be directly nailing or bolts on the
hook hanging heavy objects, such as fire hydrant, kitchen ventilator, water
heater, etc.
